Seplos BMS 2.0 supports 48V 200A charge-discharge current batteries. Models 7S, 13S, and 14S are for NCM batteries, while 8S, 15S, and 16S are for LiFePO4 batteries—do not mix battery types. This BMS protects against overcharging, over-discharging, overcurrent, and overheating.
Features
Passive balancing
Pre-charge
Heating function (optional)
Aerosol (optional)
Bluetooth monitoring (optional)
Technical specifications
16S 200A
Item
Min.
Max.
Type
Standard working voltage
41V
59V
48V
Standard charging voltage
30V
60V
54V
Working temperature range
-20℃
70℃
25℃
Continuously charging current
200A
Continuously discharging current
200A
Discharge output impedance
<2mΩ
<2mΩ
<2mΩ
Power consumption
<40mA
<40mA
<40mA
Sleeping mode power consumption
50uA
0uA
Working temperature:-20℃-70℃ Pre-charging:0-3000ms Current Balance: Passive balance:150mA(Max) Power consumption: Working mode power consumption:<40mA Sleeping mode power consumption:0 μA Capacity protection: Nominal capacity:5-500Ah Remaining capacity protection:5% Short circuit protection lock: Continuously short in the output circuit Short circuit protection lock times:5 times Short circuit protection lock release: Connected with charger Individual cell voltage protection: Over voltage protection:3650mV Under voltage protection:2700mV Over voltage protection:57.6V Under voltage protection:41.6V Over current protection:110/160A/210A Over current protection time delay:30mS Passive current limiting:10A Heating function Start:0℃/Stop:10℃ Size:300*100*30mm
